Rod Seal BU Series

BU are made up of high performance 93 Shore A PU nutrings and POM back up ring.Designed specially for rod applications, our BU rod nutring operate excellent by the help of POM ring in preventing the problems caused by permissible gap.

Technical Data
Pressure:  500 Bar
Temperature: -35 to +110
Speed: 0.5m/s
Media: Hydraulic oils (mineral oil-based)

Material
Material: PU back-up ring: POM
Hardness: 93 2 Shore A
Color: Turquoise Back-up ring: Black

Advantages
Unusually high wear resistance
High abrasion resistance
Low compression set
Easy installation
