Honeywell STD725-E1AS4AS-1-I-FHS-11C-B- 01A7 TP,FX,FG,F1-0000 Differential Pressure Transmitter

The Honeywell STD725 pressure transmitter, part of the SmartLine series, utilizes a high-performance piezoresistive sensor to accurately measure pressure. This sensor integrates multiple measurements, including process pressure, static pressure (for differential pressure models), and temperature for compensation, resulting in superior overall performance. The transmitter converts the measured pressure into a proportional electrical signal (4-20mA) and can also output digital signals via HART protocol.

Transmitter Datasheet

Transmitter Feature

• Manufacturer :  Honeywell Differential pressure Transmitter
• Product No. : STD725-E1AS4AS-1-I-FHS-11C-B- 01A7 TP,FX,FG,F1-0000
• Model :STD725 - a. Measurement URL 400/(1000) / LRL -400/(-1000) / Max Span 400/(1000) / Min Span 4.0 (10) / Units " H2O (mbar)
  Range
• a. Process Wetted Heads & Diaphragm Materials: E - Process Head Material  316 Stainless Steel / Diaphragm Material 316L Stainless Steel
• Fill Fluid: 1 -  Silicone Oil 200
• c. Process Connection: A - None (1/4" NPTF female thread Std)
• d. Bolt/Nut Materials: S - 316 SS
• e. Vent/Drain Type/Location: 4 - Head Type Dual Ended / Vent Type Standard Vent / Location End / Vent Material Matches Head Material1
• f. Gasket Material: A - Teflon® or PTFE (Glass Filled)
• g. Static Pressure: S - Standard Static Pressure - 4500 psig (315 bar)
• Head/Connect Orientation: 1  - Standard / High Side Left, Low Side Right2 / Std Head Orientation
• Approvals: I  - 316 St. St. EAC-Customs Union(Russia,Belarus and Kazakhstan)EX Approval Flameproof,Intrinsically Safe

Continue

• a. Electronic Housing Material & Connection Type: F  - Material  316 Stainless Steel (Grade CF8M) / Connection M20 / Lightning Protection None
• b. Output/ Protocol: H  - Analog Output 4-20mA dc / Digital Protocol HART Protocol
• c. Customer Interface Selections: S - Standard (w/Internal Zero,Span & Config Buttons / Ext Zero, Span & Config Buttons None / Languages EN, RU
• Factory Mutual: F1D3 - Approval Type Non-Incendive / Location or Classification  Class I, Div. 2, Groups A,B,C,D

Continue - CONFIGURATION SELECTIONS

• a. Application Software: 1 - Standard Diagnostics
• b. Output Limit, Failsafe & Write Protect Settings: 1 - Write Protect Disabled / Fail Mode High> 21.0mAdc / High & Low Output Limits3 Honeywell Std (3.8 - 20.8 mAdc)
• c. General Configuration: C - Custom Configuration (Unit Data Required from customer)

• Continue -  CALIBRATION & ACCURACY SELECTIONS
• Accuracy and Calibration: B - Standard Diagnostics
• a. Mounting Bracket: 0 - Bracket Type None / Material None
• b. Customer Tag: 1 - One Wired Stainless Steel Tag (Up to 4 lines 26 char/line)
• c. Unassembled Conduit Plugs & Adapters: A7 - M20 316 SS Certified Conduit Plug
• Certifications & Warranty: TP - Over-Pressure Leak Test Certificate (1.5X MAWP)
• Certifications & Warranty: FX - EN10204 Type 3.1 Material Traceability
• Certifications & Warranty: F1 - Calibration Test Report & Certificate of Conformance
• Factory: 0000  - Factory Identification

Basic Ordering Information Transmitter

There are several Model of pressure transmitters, for more details read the PDF below
