Honeywell STD924-L1A-00000-H6,TP,TG+ SS,SM,SH,FX,F1,CC,A7,3C+XXXX Differential Pressure Transmitter

The Honeywell STD924 is a differential pressure transmitter that measures the difference in pressure between two points and converts it into a usable output signal. It utilizes a piezoresistive sensor, along with static pressure and temperature compensation, to accurately measure pressure and provide a stable 4-20mA analog signal, and optionally, digital communication

Transmitter Datasheet

Transmitter Feature

• Manufacturer :  Honeywell
• Product No. : STD924-L1A-00000-H6,TP,TG+ SS,SM,SH,FX,F1,CC,A7,3C+XXXX
• Model :STD924 - 0-4" to 0-400" H2O / 0-10 to 0-1,000 mbar Body Rating: 4,500 psi (310 bar)
  Range
• Materials of Construction: L - Process Wetted Heads Monel 400® 4, 7 / Vent/Drain Valves and Plugs2 Monel 400® 4, 7 / Barrier Diaphragms Monel 400® 4, 7
• Fill Fluid: 1 -  DC® 200 Silicone
• Process Head Configuration: A - 1/4 NPT
• No Selection: 0000 - No Selection
• Communication Options: H6 -HART® 6.x Protocol Compatible Electronics
• Services/Certificates/Marine Type Approvals Options: TP  - Over-Pressure Leak Test with Certificate ( F3392 )
• Transmitter Housing & Electronics Options: TG  - Stainless Steel Customer Wired-On Tag (4 lines, 26 characters per line, customer supplied information)
• Meter Body Options:  SS  - 316 SS Bolts and 316 SS Nuts for Process Heads
• Indicating Meter Options: SM - Smart Meter
• Transmitter Housing & Electronics Options:  SH  - 316 SS5 Electronics Housing - (with M20 conduit connections)
• Services/Certificates/Marine Type Approvals Options: FX - Material Traceability Certification per EN 10204 3.1 (FC33341)
• Services/Certificates/Marine Type Approvals Options: F1 - Calibration Test Report and Certificate of Conformance (F3399)
• Transmitter Housing & Electronics Options: CC - Custom Calibration and I.D. in Memory
• Transmitter Housing & Electronics Options: A7 - M20 316 SS Certified Conduit Plug (ATEX, CSA & IECEx)
• Approval Body: 3C - see datasheet
• Transmitter Housing & Electronics Options:  SH  - 316 SS5 Electronics Housing - (with M20 conduit connections)
• Factory Identification: XXXX

Basic Ordering Information Transmitter

There are several Model of pressure transmitters, for more details read the PDF below

Basic Ordering Information
