Flow Transmitter 4-20mA Loop Calculator

Based on Input parameters which could be of any kind range such as m3/h or gallons/h etc. In base on this Input, the calculator shows 4-20mA of output accordingly. It is also shown a conversion scale graphic between range & 4-20mA.

Formula

This flow transmitter output calculator uses the following formula to calculate the output over a 4-20mA range:

Linear mA out = 4 + (16 x ((Rdg - Low Limit) / (High Limit - Low Limit)))
